Stage 3 of 5 · Industrial data
One trusted record of the operation.
The AVEVA PI System collects high-fidelity, time-series data from across your control systems and stores it as a single, reliable history. Asset Framework adds the context of which tag belongs to which asset, so data can be reused across sites.
- AVEVA Select Partner
- IEC 62443
- ISA-18.2
- Cyber Security Act, 2020
Industrial data
What we do
- PI System architecture and deployment
- Interface configuration
- Asset Framework modelling
- Data quality and historian health checks
The operating data path
Where this stage fits
Each stage builds on the one before it. Select a stage to explore it.
05 Decision
Better decisions at every level.
Operators respond sooner, engineers find root causes faster, and leadership sees performance across sites with confidence in the numbers.
- Operators
- Engineers
- Leadership
People
04 Intelligence
Information people actually use.
Data only creates value when the right people can see it clearly.
- PI Vision
- Dashboards
- Operational analytics
Level 4
OT security separates the plant network from the enterprise network and protects the data path between them.
- Firewall
- DMZ
- IEC 62443
Level 3.5
Enterprise networkOT networkOne trusted record of the operation.
The AVEVA PI System collects high-fidelity, time-series data from across your control systems and stores it as a single, reliable history.
- PI System historian
- Asset Framework
- Data quality
Level 3
Reliable control at the plant floor.
PLCs, DCS, SCADA and HMIs run the process minute by minute.
- PLC / DCS
- SCADA
- HMI
Levels 1–2
01 Plant
Where operational data begins.
Every pump, mill, turbine and line generates signals about how the operation is performing.
- Machines
- Equipment
- Sensors
Level 0
Technologies
The AVEVA PI System, layer by layer
- 01Interfaces and connectorsCollect data from control systems and other sources.
- 02Data ArchiveStores high-fidelity time-series data efficiently over many years.
- 03Asset FrameworkModels equipment and sites with templates, so data has context.
- 04Analyses and event framesCalculations, and records of events such as downtime or batches.
Outcome
Clean, contextualised data that engineers can rely on.
